Electric wheel loader G2200E

With the G2200E, Tobroco-Giant introduces its first electric wheel loader. The G2200E combines the best of both worlds with the advantages of an articulated loader and virtually silent operation with no emissions. The mini loader is ideal for working in buildings, around animals, or on construction sites in urban areas.

The G2200E comes standard with a 260 Ah, 48V lithium-ion battery that fills the space where the traditional engine is usually located (optional 390 Ah and 520 Ah batteries are available). With two separate electric motors, 7 kW for propulsion and 12 kW for hydraulic work, there is always sufficient power to perform tasks precisely. Furthermore, the machine regenerates energy when rolling out or descending a hill.

With a lift height of 2.85 meters and a lift capacity of 1,650 kg, the G2200E is perfect for use in height-sensitive environments.

Standard version

Hitch: GIANT Standard (Hydraulically)
ROPS / FOPS safety roof, incl. safety doors left and right
Double acting valve at the front (mechanical)
Hydraulic servicebreak on 4 wheels
Luxury seat with safety belt, armrest and extended backrest
Lithium-ion battery 260 Ah, 48 V (195 kg) (390 Ah or 520 Ah is optional)
Standard "on board" 40A charger 230V.
Main switch
Towing hook at the back
Working light (LED) at the front
Cyclone filter

Tipping loads of the machine

The table shows the tipping loads at different positions of the machine. The tipping load is the maximum weight the machine can lift while remaining stable and not tipping. The actual tipping load depends on the configuration of the machine, such as various options, attachments and working position.

G2200E Tipping Loads / Devrilme Yükleri
Position / Konum	Load / Yük (kg)
S	1.500 kg
T	1.390 kg
U	1.080 kg
V	845 kg
W	2.360 kg
X	1.645 kg
Y	1.175 kg
Source: TOBROCO-GIANT product information sheet. Values depend on machine configuration, attachment and working position.

G2200E Specifications
Service weight ¹	2200 kg
Tipping Load ²	1645 kg
Length without bucket	2890 mm
Width on standard tires	1080 mm
Travel Speed	0-4,5 / 0-12 / 0-18 km/h
Energy recuperation	Automatic battery charging while braking
Differential	Limited slip on front axle
Hill-Hold control	Automatic brake prevents rolling back on a slope
Lifting capacity	1650 kg
Lifting height ²	2800 mm
Machine height ³	2300 mm
Standard tires	10.0/75x15.3 AS
Electric motor	6,5 kW
Type	Electric four wheel drive with cardan shaft
Pulling force	12500 N
Parking brake	Electronic brake on the electric motor
¹ Measured with earthbucket
² Measured with counterweight and driver ± kg
³ Measured on standard tyres with safety roof
